High Voltage Transducers

In high-voltage environments with several thousand volts, our highly insulated voltage and current transducers and temperature transmitters rely on perfect galvanic isolation to ensure the highest safety possible for persons and systems. The motor generators for DC and AC voltages can also be used for precise energy measurement for billing. Moreover, the range includes voltage presence detectors (VPD) with insulation of up to 4800 V that detect and report dangerous voltages applied in high-voltage environments. For current measurement up to the kA range, the accessory range offers shunt resistors with low voltage drops, a high level of accuracy, and high overload capacity.

Filter

Filter
P43000 High Voltage Transducer | Input up to ±5 A | Direct measurement
P43000 High Voltage Transducer | Input up to ±5 A | Direct measurement
Product number:

P43000

Function: Measurement of currents at high potential

Input: 0 ... (±)0.1 A upt to 0 ... (±)5 A

Isolation AC/DC: up to 3,600 V

P42000 TRMS AC/DC High Voltage Transducer | Input up to ±3600 V | True RMS measurement
P42000 TRMS AC/DC High Voltage Transducer | Input up to ±3600 V | True RMS measurement
Product number:

P42000TRMS

Input: 0 ... 3600 V AC, 0 ... 10 V AC

Isolation AC/DC: 2,200 V, up to 3,600 V

P41000AG High Voltage Transducer | Input up to ±120/1320 mV | Nominal current and overcurrent measurement
P41000AG High Voltage Transducer | Input up to ±120/1320 mV | Nominal current and overcurrent measurement
Product number:

P41000AG

Input: 0 ... (±)30/330 mV up to 0 ... (±)120/1320 mV

Isolation AC/DC: up to 3,600 V

P41000 High Voltage Transducer | Input up to ±100 V | High isolation up to 3600 V
P41000 High Voltage Transducer | Input up to ±100 V | High isolation up to 3600 V
Product number:

P41000

Input: 0 ... (±)50 mV up to 0 ... (±)100 V

Isolation AC/DC: up to 3,600 V

P52000 VPD High Voltage Transducer | Input max. 4200 V DC or AC peak | Voltage presence detection
P52000 VPD High Voltage Transducer | Input max. 4200 V DC or AC peak | Voltage presence detection
Product number:

P52000VPD

Input: 50 V ... 4200 V, 0 ... (±)100 V up to 0 ... (±)4800 V, max. 4800 V DC or AC peak

Isolation AC/DC: up to 4,800 V

P43000 TRMS AC/DC High Voltage Transducer | Input up to ±5 A | True RMS measurement
P43000 TRMS AC/DC High Voltage Transducer | Input up to ±5 A | True RMS measurement
Product number:

P43000TRMS

Input: 0 ... 5 A AC, 0 ... 100 mA AC

P42000 High Voltage Transducer | Calibrated range selection
P42000 High Voltage Transducer | Calibrated range selection
Product number:

P42000

Function: Measurement of high voltages

Input: 0 ... (±)100 V up to 0 ... (±)3600 V

Isolation AC/DC: 2,200 V, up to 3,600 V

P51000 High Voltage Transducer | Input up to ±125 V | Current measurement | Energy metering
P51000 High Voltage Transducer | Input up to ±125 V | Current measurement | Energy metering
Product number:

P51000

Input: 0 ... (±)30 mV up to 0 ... (±)100 V

Isolation AC/DC: up to 4,800 V

Shunt resistors | High overload capacity | Immune to stray fields
Shunt resistors | High overload capacity | Immune to stray fields
Product number:

maconic

Input: 0 ... 1 A up to 0 ... 20 kA

P41000 TRMS AC/DC High Voltage Transducer | Input up to ±100 V | True RMS measurement
P41000 TRMS AC/DC High Voltage Transducer | Input up to ±100 V | True RMS measurement
Product number:

P41000TRMS

Input: 0 ... 10 V AC, 0 ... 50 mV AC

P44000 Temperature Transmitter | Input Pt100 resistance thermometer (RTD) | High isolation up to 6600V
P44000 Temperature Transmitter | Input Pt100 resistance thermometer (RTD) | High isolation up to 6600V
Product number:

P44000

Input: 0 ... 100 °C, 0 ... 300 °C, 0 ... 200 °C

Isolation AC/DC: up to 2,000 V, up to 6,600 V

P29000 High Voltage Transducer | Calibrated range selection
P29000 High Voltage Transducer | Calibrated range selection
Product number:

P29000

Function: Voltage measurement, Current measurement via shunt resistor

Input: 0 ... (±)30 mV up to 0 ... (±)100 V, 0 ... (±)100 V up to 0 ... (±)1000 V

Isolation AC/DC: up to 1,000 V

P45000 High Voltage Transducer | Input up to ±3000 V overrange up to 150% | For use in SIL2 systems, redundantly in SIL3
P45000 High Voltage Transducer | Input up to ±3000 V overrange up to 150% | For use in SIL2 systems, redundantly in SIL3
Product number:

P45000

Input: 0 ... (±)2000 V, 0 ... (±)1000 V, 0 ... (±)2800 V, 0 ... (±)3000 V, Overrange up to 150 %, 0 ... (±)500 V, 0 ... (±)750 V, 0 ... (±)1500 V

Isolation AC/DC: up to 3,600 V AC, 4,800 V DC

P52000 High Voltage Transducer | Input up to ±4800 V | Voltage measurement | Energy metering
P52000 High Voltage Transducer | Input up to ±4800 V | Voltage measurement | Energy metering
Product number:

P52000

Input: 0 ... (±)100 V up to 0 ... (±)4800 V

Isolation AC/DC: up to 4,800 V
