SE603 4-Electrode Conductivity Sensor | Fixed cable | Very high corrosion resistance
Description
4-electrode sensor with large measuring range providing maximum corrosion resistance, sensor materials: PTFE and platinum.
- High level of chemical resistance due to corrosion-proof materials
- Large measuring range due to 4-electrode technology
- Measurement at high temperatures and pressures
- Slim, ultracompact design
For special chemistry applications, universal measuring range from pure water to 600 mS/cm. With fixed cable and integrated temperature detector. Process-wetted materials: PTFE and platinum. Ultracompact design.
We look forward to hearing from you!
Contact Us
| Measurement Parameter: |
Conductivity
|
|---|---|
| Measuring Range: |
Approx. 0.5 µS/cm … 600 mS/cm
|
| Process Connection: |
Special flange
|
| Temperature: |
Max.120 °C
|
| Temperature Detector: |
Pt1000 (IEC Class A)
|
| Body Material: |
PTFE
|
| Measuring principle: |
4 electrodes
|
| Pressure: |
Max. 12 bar
|
| Electrode Material: |
Platinum
|
| Cable: |
Fixed cable, 5 m
|
| Cell constant: |
0.14 … 0.38 cm (exact value on nameplate)
|
