SE559 pH Sensor | Memosens | 120 mm | Ex | For water and analytical chemistry

Length
Product number: SE559X/1-NMSN
Description Technical details Downloads Use cases Blog posts

Description

SE559 pH Sensor | Memosens | 120 mm | Ex | For water and analytical chemistry

For uncomplicated measurement in water and analytical chemistry, digital, with Memosens technology.

  • No influence of humidity in the connector
  • Precalibration in the lab
  • Digital data transfer
  • Integrated sensor diagnostics
  • Low maintenance, no refilling of electrolyte
  • Integrated temperature detector
  • Calibrated annular junction
  • Independent of flow
  • Alpha glass, medium impedance, universal glass, fluoride resistant

The calibrated annular junction enables precise measurements in process media virtually without influence of flow.The large contact surface of the junction minimizes problems caused by contamination.

The sensor is ideal for processes for which liquid-electrolyte sensors should be used, but where maintenance is impossible for a longer period of time.

Applications
Water supply and distribution, chemical processes.

We look forward to hearing from you!
Contact Us

Technical details

Measurement Parameter: pH
Connector: Memosens
Explosion protection: Ex
Length: 120 mm
Process Connection: PG 13.5
Measuring Range: 0 … 14 pH
Temperature: –5 … 100 °C (23 ... 212 °F)
Pressure, relative: 0 … 6 bar
Temperature Detector: NTC 30 kΩ
Junction: Calibrated annular junction
Reference System: Ag/AgCl, polymer electrolyte
Sensor Material: Alpha glass
