SE603 4-Electrode Conductivity Sensor | Fixed cable | Very high corrosion resistance

商品编号: SE603
Compare
Compare
说明 技术细节 下载 在工艺或应用中使用 相关的博客文章

Description

SE603 4-Electrode Conductivity Sensor | Fixed cable | Very high corrosion resistance

4电极传感器，具有非常宽的测量范围和非常高的耐腐蚀性，能够承受高压和高温。传感器材料：PTFE和铂。

  • 高等级耐化学腐蚀材料
  • 采用四电极技术可适用于大量程测量
  • 适用于高温高压测量
  • 修长、紧凑型设计

适合特殊化学应用，从纯水到600 mS/cm的通用测量范围。具有固定电缆并集成温度检测器。工艺浸湿材料：PTFE和铂。超紧凑式设计。

我们期待您的来信
联系我们

技术细节

Pressure: 最大 12 bar
工艺连接: 特殊法兰
杆材料: PTFE
测量原理: 4电极
测量参数: 电导率（接触式）
测量范围: ca. 0,5 µS/cm … 600 mS/cm
温度: max. 120 °C
温度检测器: Pt1000 (IEC-Klasse A)
电极材料: 铂
电池常数: 0,14 … 0,38 cm (genauer Wert auf Typschild)
电缆: 5 m 固定电缆

下载

小册子

[13395] 宣传册
传感器 - 适用于测量pH/氧化还原值、电导率和氧。数字式与模拟式。

证书

[14516] EU Declaration of Conformity (DE, EN, FR)
No. EU210621A | 2021-06-21
Analog Sensors, non Ex
