SE515 pH Sensor | Memosens | 120 mm | Sigma glass | For water and wastewater treatment

商品编号: SE515/1-MS
Compare
Compare
说明 技术细节 下载 在工艺或应用中使用 相关的博客文章

Description

SE515 pH Sensor | Memosens | 120 mm | Sigma glass | For water and wastewater treatment

价格合理的传感器，适用于水和废水处理

  • 利用Memosens技术实现完善的电流隔离
  • 连接器的湿度无影响
  • 实验室预校准
  • 以数字方式传输数据
  • 集成传感器诊断功能
  • 低维护，无需重新添加电解质
  • 集成温度检测器
  • 毛玻璃套管连接
  • Sigma玻璃；低阻抗，适合低温应用

得益于其毛玻璃套管连接，甚至适用于重度污染介质。专为MemoRail应用而设计。通过特殊设计实现高稳定性及长寿命周期。

参考系统通过毛玻璃套管连接与被测介质直接接触。连接几乎不存在污染或堵塞风险。

得益于特殊的低阻抗玻璃，即使在低温下，也可以进行测量。

我们期待您的来信
联系我们

技术细节

传感器材料: 低阻抗Sigma玻璃
参考系统: 银/氯化银，电解质凝胶
工艺连接: PG 13.5
插接头: Memosens
是否防爆: 非 Ex
测量参数: pH
测量范围: 0 … 14 pH
温度: –5 … 80 °C ( 23 ... 176 °F)
温度检测器: NTC 30 kΩ
相对压力: 0 … 4 bar
长度: 120 mm
隔膜: 接地玻璃套管

下载

操作说明书

[16286] User Manual (DE, EN, KO)
Memosens Cable CA/MS
Version 09
[14165] User Manual (DE, EN)
ZU 1054 Sensor Protection (Sensorschutz)
[4497] General Instructions (DE, EN, FR, ES, IT)
SE515/1 MS pH Sensor
Version 01

数据手册

[2138] Data sheet
SE515 Memosens pH Sensor
Product Description | Specifications | Product Range

证书

[14511] EU Declaration of Conformity (DE, EN, FR)
No. EU220118A | 2022-01-18
Digital Sensors, non Ex
[14155] Declaration of Compliance 2.1 (DE, EN)
according to EN 10204 | gemäß EN 10204
[12781] EU Declaration of Conformity (DE, EN, FR)
No. EU210706D | 2021-07-06
Memosens Measuring Cable Type CA/MS-...X.., CA/MS-...X..-L
[11671] EU Declaration of Conformity (DE, EN, FR)
No. EU181113B | 2018-11-13
SE515 Memosens

Safety guides

[11045] Material Safety Data Sheet
CaliMat buffer solution pH 7,00
[11048] Material Safety Data Sheet
CaliMat buffer solution pH 4,00
[11046] Material Safety Data Sheet
CaliMat buffer solution pH 9,00
[11049] Material Safety Data Sheet
CaliMat buffer solution pH 2,00
[11044] Material Safety Data Sheet
CaliMat buffer solution pH 12,00

我们的服务

Lorem lorem ipsum ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor invidunt ut labore et dolore magna aliquyam erat, sed diam voluptua. At vero eos et accusam et justo duo dolores et ea rebum. Stet clita kasd gubergren, no sea takimata sanctus est Lorem ipsum dolor sit amet. Lorem ipsum dolor sit amet, consetetur sadipscing elitr, sed diam nonumy eirmod tempor invidunt ut labore et dolore magna aliquyam erat, sed diam voluptua. At vero eos et accusam et justo duo dolores et ea rebum. Stet clita kasd gubergren, no sea takimata sanctus est Lorem ipsum dolor sit amet.

在工艺或应用中使用

过程分析
Knick 提供创新的工业变送器、高品质传感器、创新的连接件以及独特的清洁和校准系统

相关产品

SE503 pH Sensor | VP | 120 mm | Polysulfone Body | For water and wastewater treatment
SE503 pH Sensor | VP | 120 mm | Polysulfone Body | For water and wastewater treatment
商品编码:

SE503N/1-NVPN

SE515 pH Sensor | Memosens | 120 mm | Sigma glass | For water and wastewater treatment
SE515 pH Sensor | Memosens | 120 mm | Sigma glass | For water and wastewater treatment
商品编码:

SE515/1-MS

SE547N pH Sensor | Memosens | 120 mm | CIP/SIP capable and autoclavable
SE547N pH Sensor | Memosens | 120 mm | CIP/SIP capable and autoclavable
商品编码:

SE547N/1-NMSN-A2

SE547N pH Sensor | Memosens | 225 mm | CIP/SIP capable and autoclavable
SE547N pH Sensor | Memosens | 225 mm | CIP/SIP capable and autoclavable
商品编码:

SE547N/2-NMSN-A2

SE554 pH Sensor | Memosens | 120 mm | Ex | For very high ionic strength media
SE554 pH Sensor | Memosens | 120 mm | Ex | For very high ionic strength media
商品编码:

SE554X/1-NMSN

SE554 pH Sensor | Memosens | 225 mm | Ex | For very high ionic strength media
SE554 pH Sensor | Memosens | 225 mm | Ex | For very high ionic strength media
商品编码:

SE554X/2-NMSN

SE554 pH Sensor | Memosens | 325 mm | Ex | For very high ionic strength media
SE554 pH Sensor | Memosens | 325 mm | Ex | For very high ionic strength media
商品编码:

SE554X/3-NMSN

SE554 pH Sensor | Memosens | 425 mm | Ex | For very high ionic strength media
SE554 pH Sensor | Memosens | 425 mm | Ex | For very high ionic strength media
商品编码:

SE554X/4-NMSN

SE554 pH Sensor | VP | 120 mm | Ex | For very high ionic strength media
SE554 pH Sensor | VP | 120 mm | Ex | For very high ionic strength media
商品编码:

SE554X/1-NVPN

SE554 pH Sensor | VP | 225 mm | Ex | For very high ionic strength media
SE554 pH Sensor | VP | 225 mm | Ex | For very high ionic strength media
商品编码:

SE554X/2-NVPN

SE554 pH Sensor | VP | 325 mm | Ex | For very high ionic strength media
SE554 pH Sensor | VP | 325 mm | Ex | For very high ionic strength media
商品编码:

SE554X/3-NVPN

SE554 pH Sensor | VP | 425 mm | Ex | For very high ionic strength media
SE554 pH Sensor | VP | 425 mm | Ex | For very high ionic strength media
商品编码:

SE554X/4-NVPN

SE554 pH/ORP Sensor | Memosens | 120 mm | Ex | For very high ionic strength media
SE554 pH/ORP Sensor | Memosens | 120 mm | Ex | For very high ionic strength media
商品编码:

SE554X/1-AMSN

SE554 pH/ORP Sensor | Memosens | 225 mm | Ex | For very high ionic strength media
SE554 pH/ORP Sensor | Memosens | 225 mm | Ex | For very high ionic strength media
商品编码:

SE554X/2-AMSN

SE555 pH Sensor | Coax (S8) | 120 mm | Ex | Sterilizable | For aggressive media
SE555 pH Sensor | Coax (S8) | 120 mm | Ex | Sterilizable | For aggressive media
商品编码:

SE555X/1-NS8N

SE555 pH Sensor | Coax (S8) | 225 mm | Ex | Sterilizable | For aggressive media
SE555 pH Sensor | Coax (S8) | 225 mm | Ex | Sterilizable | For aggressive media
商品编码:

SE555X/2-NS8N

SE555 pH Sensor | Memosens | 120 mm | Ex | PWIS-free | Sterilizable | For aggressive media
SE555 pH Sensor | Memosens | 120 mm | Ex | PWIS-free | Sterilizable | For aggressive media
商品编码:

SE555X/1-NMSN-LABS

SE555 pH Sensor | Memosens | 120 mm | Ex | Sterilizable | For aggressive media
SE555 pH Sensor | Memosens | 120 mm | Ex | Sterilizable | For aggressive media
商品编码:

SE555X/1-NMSN

SE555 pH Sensor | Memosens | 225 mm | Ex | Sterilizable | For aggressive media
SE555 pH Sensor | Memosens | 225 mm | Ex | Sterilizable | For aggressive media
商品编码:

SE555X/2-NMSN

SE555 pH Sensor | Memosens | 325 mm | Ex | Sterilizable | For aggressive media
SE555 pH Sensor | Memosens | 325 mm | Ex | Sterilizable | For aggressive media
商品编码:

SE555X/3-NMSN

SE555 pH Sensor | Memosens | 425 mm | Ex | Sterilizable | For aggressive media
SE555 pH Sensor | Memosens | 425 mm | Ex | Sterilizable | For aggressive media
商品编码:

SE555X/4-NMSN

SE555 pH Sensor | VP | 120 mm | Ex | Sterilizable | For aggressive media
SE555 pH Sensor | VP | 120 mm | Ex | Sterilizable | For aggressive media
商品编码:

SE555X/1-NVPN

SE555 pH Sensor | VP | 225 mm | Ex | Sterilizable | For aggressive media
SE555 pH Sensor | VP | 225 mm | Ex | Sterilizable | For aggressive media
商品编码:

SE555X/2-NVPN

SE555 pH Sensor | VP | 325 mm | Ex | Sterilizable | For aggressive media
SE555 pH Sensor | VP | 325 mm | Ex | Sterilizable | For aggressive media
商品编码:

SE555X/3-NVPN

SE555 pH Sensor | VP | 425 mm | Ex | Sterilizable | For aggressive media
SE555 pH Sensor | VP | 425 mm | Ex | Sterilizable | For aggressive media
商品编码:

SE555X/4-NVPN

SE555 pH/ORP Sensor | Memosens | 120 mm | Ex | CIP/SIP capable | Sterilizable | For aggressive media
SE555 pH/ORP Sensor | Memosens | 120 mm | Ex | CIP/SIP capable | Sterilizable | For aggressive media
商品编码:

SE555X/1-AMSN

SE555 pH/ORP Sensor | Memosens | 225 mm | Ex | CIP/SIP capable | Sterilizable | For aggressive media
SE555 pH/ORP Sensor | Memosens | 225 mm | Ex | CIP/SIP capable | Sterilizable | For aggressive media
商品编码:

SE555X/2-AMSN

SE557 pH Sensor | Memosens | 250 mm | Ex | Alpha glass | For process media requiring high measurement stability
