SE202 Sensore di conducibilità a 2 elettrodi | Corpo in acciaio inox | Per fluidi con conducibilità da bassa a estremamente bassa
Codice prodotto:
SE202
Description
SE202 Sensore di conducibilità a 2 elettrodi | Corpo in acciaio inox | Per fluidi con conducibilità da bassa a estremamente bassa
Sensore di conducibilità a 2 elettrodi con corpo in acciaio inox
- 2 elettrodi con disposizione coassiale
- Corpo in acciaio inox
- Sonda di temperatura integrata
- Profondità di immersione min. 30 mm
Il sensore di conducibilità a 2 elettrodi SE202 con corpo in acciaio inox è un sensore per misurazioni della conducibilità all’interno di fluidi con conducibilità da ridotta a minima. È dotato di una sonda di temperatura integrata.
Applicazioni
Acqua ultrapura, acqua di alimentazione caldaie, acqua deionizzata, controllo scambiatore ionico e osmosi inversa
Non vediamo l'ora di ascoltarvi!
Contatto
| Campo di misura : | 0 … 200 µS/cm |
|---|---|
| Cavo: | Cavo fisso (lunghezza: 1,5 m / 4,90 ft) |
| Connecting head material: | POM |
| Costante di cella: | 0,1 cm–1 |
| Diametro del corpo: | 12 mm/0,47 pollici |
| Elettrodi: | Disposizione coassiale, acciaio inox 1.4571 |
| Lunghezza del corpo: | 120 mm / 4,72 pollici |
| Materiale del corpo: | Acciaio inox 1.4571 |
| Parametro di misurazione: | Conduttività |
| Pressione: | 2 bar (relative) |
| Profondità di immersione: | Min. 30 mm / 1,18 pollici |
| Risoluzione: | 0,01 μS/cm |
| Sigillo: | Viton |
| Sonda di temperatura: | Pt1000 |
| Temperatura: | –5 … 100 °C (23 ... 212 °F) |
Scaricamento
