SE202-MS Sensore di conducibilità a 2 elettrodi | Memosens | Corpo in acciaio inox | Per fluidi con conducibilità da bassa a estremamente bassa
Codice prodotto:
SE202-MS
Description
SE202-MS Sensore di conducibilità a 2 elettrodi | Memosens | Corpo in acciaio inox | Per fluidi con conducibilità da bassa a estremamente bassa
Sensore di conducibilità a 2 elettrodi con corpo in acciaio inox, digitale, con tecnologia Memosens
- Perfetto isolamento galvanico grazie alla tecnologia Memosens
- Nessuna influenza dell’umidità sul connettore
- Pretarabile
- Trasmissione dati digitale
- Diagnostica del sensore integrata
- Sonda di temperatura integrata
- Corpo in acciaio inox 1.4571
Sensore digitale a 2 elettrodi per conducibilità da ridotte a minime.
La tecnologia Memosens digitale senza contatto offre notevoli vantaggi relativi a gestione e sicurezza della misurazione. L’impugnatura del sensore memorizza i dati di calibrazione, il tempo di esercizio,
il nome del sensore e il numero di serie.
Applicazioni
Misurazione in fluidi a bassa conducibilità come acqua ultrapura / acqua di alimentazione caldaie, acqua deionizzata o sottoposta a scambio ionico
Non vediamo l'ora di ascoltarvi!
Contatto
| Campo di misura : | 0 … 200 µS/cm |
|---|---|
| Costante di cella: | 0,1 cm–1 |
| Elettrodi: | Disposizione coassiale, acciaio inox 1.4571 |
| Impugnatura del sensore: | Connettore Memosens, adatto al pozzetto Portavo |
| Isolatore: | POM |
| Lunghezza: | 120 mm |
| Materiale del connettore: | PPS/PVC/EPDM |
| Materiale del corpo: | Acciaio inox 1.4571 |
| Parametro di misurazione: | Conduttività |
| Pressione: | 1 bar (relative) |
| Profondità di immersione: | Min. 35 mm |
| Sigillo: | Viton |
| Sonda di temperatura: | NTC 30 kΩ |
| Temperatura: | –5 … 80 °C ( 23 ... 176 °F) |
